USB Smart Charging System

USB type C up to 60W
USB smart charging system for high-powered devices
USB Smart Charging System

Producto

Description

Reduced size
In our challenge to achieve minimalism and shape, our 36W and 60W smart USB type C chargers are the result of our commitment to R&D, launching compact devices in reduced dimensions 45x45mm that can be integrated into all of our product ranges.

Smart charging
Our high-power type C charging modules are compatible with the Power Delivery 3.0 standard. Our modules allow to charge your devices as smartphones, tablets or laptops quickly and easily.

No external power
None of our charging modules require their independent connection to the power, since they are directly connected to the electric current. For this reason, they are considered as one more socket outlet and cannot be incorporated later in the data and multimedia custom-module area.

Applications

USB TYPE C (36W)

Dimension: 1 module (45x45mm).
Power: 36W.
Input: AC100-265V 50/60Hz.
Output voltage: DC5V-20V.
Output current: 3A max.
Voltages: Power Delivery 3.0 5V-3A / 9V-3A / 12V-3A / 15V-2,4A / 20V-1,8A.





USB TYPE C (60W)

Dimension: 1 module (45x45mm).
Power: 60W.
Input: AC100-265V 50/60Hz.
Output voltage: DC5V-20V.
Output current: 3A max.
Voltages: Power Delivery 3.0 5V-3A / 9V-3A / 12V-3A / 15V-3A / 20V-3A.
